| Attribute name | Attribute value |
|---|---|
| Main | |
| Device short name | 9001K |
| Operator profile | 80 mm long operating shaft |
| Sale per indivisible quantity | 1 |
| Product or component type | head for joystick controller |
| Type of operator | spring return |
| Range of product | Harmony 9001K |
| Complementary | |
| Return | to centre |
| Operating position | any position |
| Type of operator | spring return |
| Compatibility code | 9001K |
| Bezel material | metal |
| Contacts type and composition | without contact block |
| Device presentation | basic element |
| Size | 30 mm |
| Net weight | 0.372 kg |
| Operator direction information | 4 directions |
| Shape of signaling unit head | octagonal |
| Mounting diameter | 30 mm |
| Environment | |
| Protective treatment | TC |
| NEMA degree of protection | NEMA 4, NEMA 3R, NEMA 3, NEMA 2, NEMA 13, NEMA 12, NEMA 1 |
| Overvoltage category | II conforming to IEC 61140 |
| Ambient air temperature for storage | -40-70 °C |
| IP degree of protection | IP66 conforming to IEC 60529 |
| Vibration resistance | 7 gn (f= 2-500 Hz) conforming to IEC 60068-2-6 |
| Shock resistance | 50 gn conforming to IEC 60068-2-27 |
| Standards | JIS C8201-1, IEC 60947-5-4, IEC 60947-1, UL 508, IEC 60947-5-1, CSA C22.2 No 14, JIS C 852, JIS C8201-5-1 |
| Ambient air temperature for operation | -25-70 °C |
| Product certifications | NEMA, UL 508 |
