| Attribute name | Attribute value |
|---|---|
| Main | |
| Device short name | ZBV |
| Light source colour | white |
| Sale per indivisible quantity | 5 |
| Light block supply | direct |
| Range of product | Harmony XB4, Harmony XB5 |
| Bulb base | integral LED |
| [Us] rated supply voltage | 230...240 V AC at 50/60 Hz |
| Signalling type | steady |
| Connections - terminals | push-in, >= 1 x 0.34 mm² without wire end ferrule conforming to EN 60947-1, push-in, <= 2 x 1.5 mm² with wire end ferrule conforming to EN 60947-1 |
| Product or component type | light block |
| Light source | universal LED |
| Complementary | |
| Shape of screw head | compatible with flat Ø 4 mm screwdriver |
| Compatibility code | ZBV |
| Supply voltage limits | 195-264 V AC |
| Surge withstand | 2 kV common mode, 1 kV differential mode conforming to IEC 61000-4-5 |
| Device presentation | basic element |
| CAD overall height | 14.8 mm |
| Electrical composition code | PF1, P2, P1, MF1, M10, M6, M5, M4, M3, M2, M1 |
| CAD overall depth | 9.8 mm |
| CAD overall width | 35.6 mm |
| Service life | 100000 h at rated voltage and 25 °C |
| Current consumption | 14 mA |
| Net weight | 0.012 kg |
| Mounting of block | front mounting |
| Environment | |
| Protective treatment | TH |
| Resistance to electrostatic discharge | 8 kV in free air (in insulating parts) conforming to IEC 61000-4-2, 4 kV on contact (on metal parts) conforming to IEC 61000-4-2 |
| Ambient air temperature for storage | -40-70 °C |
| IP degree of protection | IP20 conforming to IEC 60529 |
| Ambient air temperature for operation | -40-70 °C |
| [Us] rated supply voltage | 230...240 V |
| Electromagnetic emission | class B conforming to IEC 55011 |
| Standards | JIS C8201-1, JIS C8201-5-1, IEC 60947-5-1, CSA C22.2 No 14, UL 508, IEC 60947-1 |
| Product certifications | UL listed, CSA |
