Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Function of module | monitoring short-circuit and line break for line control outputs, monitoring safety dialogue for discrete output, monitoring safety dialogue for discrete input, monitoring safety detection for discrete input, monitoring safety actuators for discrete output, monitoring safety actuators for discrete input |
| Safety use category | SIL 3 conforming to EN/IEC 61508, performance level e conforming to EN/ISO 13849-1, category 4 maximum conforming to EN 954-1 |
| Discrete input number | 8 not isolated discrete input(s) |
| Safety module application | extension of I/O capacity |
| Safety module name | XPSMF3 |
| Structure type | 10BASE-T/100BASE-TX |
| Supply | SELV or PELV conforming to EN/IEC 60950 |
| Product or component type | Preventa safety remote mixed I/O module |
| Discrete output number | 10 , not isolated |
| Number of outputs | 2 not isolated for line control outputs |
| Range of product | Preventa Safety automation |
| [Us] rated supply voltage | 24 V DC - 15...20 % |
| Complementary | |
| Inductive load | 500 mH for discrete output |
| Minimum load | 2 mA per channel |
| Discrete output current | <= 7 A (all channels), 0.5 A at 60 °C (channels 1 to 3 and 5 to 7), 2 A at 40 °C (channels 4 and 8), 1 A at 60 °C (channels 4 and 8), 1 A at 60 °C (channels 1 and 2) |
| Depth | 66.5 mm |
| Maximum tungsten load | <25 W, channels 4 and 8 for discrete output, <25 W, channels 1 and 2 for discrete output, <10 W, channels 1 to 3 and 5 to 7 for discrete output |
| Width | 152 mm |
| Switching voltage | 7.5 V for discrete input |
| Input protection type | protected against short-circuit |
| Response time | depending on size of application |
| Current state 0 guaranteed | 1.25...1.5 mA (discrete input) |
| Voltage state 1 guaranteed | 15...< 30 V for discrete input |
| Nominal output current | 60 mA for line control outputs |
| Maximum leakage current | 1 mA, at 2 V at state 0 for discrete output |
| Communication port protocol | safe Ethernet with 2 RJ45 port(s), transmission rate: 100 Mbps, 10 Mbps, medium: dual twisted pair cable, category 5D or better |
| Discrete output voltage | 24 V DC |
| Voltage state 0 guaranteed | <= 5 V for discrete input |
| Net weight | 1 kg |
| Associated fuse rating | 10 A, slow-blow |
| Output voltage tolerance | +/- 2 % |
| Current state 1 guaranteed | <= 2 mA (discrete input) |
| Discrete input current | 100 mA |
| Current consumption | 8 A at 24 V DC on power supply |
| Exchange mode | half duplex, full duplex, autonegotiation |
| Mounting support | 35 mm symmetrical DIN rail |
| Discrete input voltage | 20 V |
| Height | 109 mm |
| Output voltage | 20 V line control outputs |
| Number of terminal blocks | 2 for line control outputs, 2 for discrete output, 2 for discrete input, 1 for power supply |
| Environment | |
| Ambient air temperature for storage | -40-85 °C |
| IP degree of protection | IP20 |
| Ambient air temperature for operation | 0-60 °C |
