Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Safety use category | SIL 3 conforming to EN/IEC 61508, performance level e conforming to EN/ISO 13849-1, category 4 maximum conforming to EN 954-1 |
| Safety module application | extension of I/O capacity |
| Safety module name | XPSMF3 |
| Structure type | 10BASE-T/100BASE-TX |
| Product or component type | Preventa safety remote mixed I/O module |
| Range of product | Preventa Safety automation |
| Complementary | |
| Depth | 207 mm |
| Input current limits | 0.4-23 mA, with 500 Ohm shunt |
| Width | 97.5 mm |
| Function of module | closed circuit scanning of input channels, measuring, using shunt, 0/4 to 20 mA currents, single-pole measuring of 0 to 10 V voltages |
| Input overvoltage protection | -4-15 V |
| Analogue input resolution | 12 bits |
| Maximum cable distance between devices | 300 mm analogue output, 300 mm analogue input circuit |
| Response time | depending on size of application |
| Load impedance ohmic | <= 600 Ohm for analogue output |
| Analogue output number | 4 |
| Analogue input number | 8 |
| Analogue output resolution | 12 bits |
| Communication port protocol | safe Ethernet with 2 RJ45 port(s), transmission rate: 100 Mbps, 10 Mbps, medium: dual twisted pair cable, category 5D or better |
| Net weight | 0.95 kg |
| Supply | SELV or PELV conforming to EN/IEC 60950 |
| Input voltage limits | 0.1...11.5 V |
| Safety accuracy | +/- 2 % for analogue input circuit |
| Analogue output range | 4...20 mA |
| Current consumption | 0.8 A at 24 V DC on power supply |
| Analogue input type | not isolated |
| Output current limits | 0-20 mA |
| Exchange mode | half duplex, full duplex, autonegotiation |
| Maximum internal input resistance | 2 Ohm, 500 MOhm for signal source |
| Analogue input range | 0...10 V, 0...20 mA with 500 Ohm shunt |
| External resistance | 500 Ohm for analogue input circuit, 250 Ohm for analogue input circuit |
| Mounting support | 35 mm symmetrical DIN rail |
| Relative error | +/- 1 % |
| Analogue output type | not isolated |
| Height | 109 mm |
| [Us] rated supply voltage | 24 V DC - 15...20 % |
| Number of terminal blocks | 5 for analogue input/output circuit, 1 for power supply |
| Environment | |
| Ambient air temperature for storage | -40-85 °C conforming to EN 61131-2 |
| IP degree of protection | IP20 (enclosure) |
| Ambient air temperature for operation | 0-60 °C |
