TeSys Vario add-on module, main pole 40A 690V, for Vario switch-disconnectors. To be used with V2 switch bodies. A maximum of 3 additional VZ2 modules can be attached to the switch body. Multi standards certified (IEC, UL, CSA, CCC, EAC),environmental compliant (RoHS/REACh). Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh).
Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Device short name | VZ |
| Product compatibility | V2 |
| Poles description | 1P |
| Suitability for isolation | yes |
| Contacts type and composition | 1 NO |
| Range | TeSys |
| Performance level | high performance |
| Product or component type | additional pole |
| Range compatibility | TeSys TeSys VARIO switch disconnector |
| Network type | DC, AC |
| Network frequency | 50/60 Hz |
| Complementary | |
| Depth | 35 mm |
| Tightening torque | power circuit: 2.1-2.1 N.m - on screw clamp terminals |
| Width | 16 mm |
| Compatibility code | main pole module |
| Mechanical durability | 100000 cycles |
| Electrical durability | 30000 cycles DC-1...5, 100000 cycles AC-21 |
| Connections - terminals | power circuit: screw clamp terminals10-10 mm² - solid, power circuit: screw clamp terminals6-6 mm² - flexible - with cable end |
| Mounting location | right, left |
| [Uimp] rated impulse withstand voltage | 8 kV |
| Net weight | 0.05 kg |
| [Ithe] conventional enclosed thermal current | 32 A |
| [Ith] conventional free air thermal current | 40 A |
| Height | 74 mm |
| [Ue] rated operational voltage | 690 V AC 50/60 Hz |
| Environment | |
| Fire resistance | 960 °C conforming to IEC 60695-2-1 |
| Mechanical robustness | shocks 11 ms (30 Gn) conforming to IEC 60068-2-27, vibrations 10...150 Hz (1 gn) conforming to IEC 60068-2-6 |
| Protective treatment | TC |
| IP degree of protection | IP20 conforming to IEC 60529 |
| Standards | IEC 60947-3 |
| Ambient air temperature for operation | -20-50 °C |
| Product certifications | UKCA, UL, GL, CSA |
