Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Protection type | integrated thermal protection by thermal probe |
| Range compatibility | Altivar Process ATV900 |
| Product compatibility | variable speed drive ATV930 without braking chopper 75 kW 200...240 V, variable speed drive ATV930 without braking chopper 55 kW 200...240 V |
| Minimum resistor value to associate | 1.4 Ohm |
| Thermal losses | 400 W |
| Complementary | |
| Depth | 303 mm |
| Width | 216 mm |
| Activation threshold | 395 V DC +/- 1 % |
| Operating position | vertical +/- 10 degree |
| Load factor | 1 for 75 kW at constant power and at engage threshold, 0.5 for 95 kW at constant power and at engage threshold, 0.15 for 120 kW at constant power and at engage threshold, 0.05 for 150 kW at constant power and at engage threshold |
| Maximum braking power | 80 kW |
| Maximum DC bus voltage | 450 V |
| Net weight | 15.5 kg |
| Permanent braking power | 60 kW (at constant power and at engage threshold) |
| Volume of cooling air | 166 m3/h |
| Height | 658 mm |
| Mechanical robustness | vibrations class 3M4 conforming to IEC 60721-3-3 |
| Environment | |
| Operating altitude | 1000...4000 m with current derating 1 % per 100 m, <= 1000 m without derating |
| Ambient air temperature for storage | -40-70 °C |
| IP degree of protection | IP21 (on top), IP20 |
| Ambient air temperature for operation | -10-50 °C |
