Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Range of product | TransferPacT |
| Product or component type | I/O module |
| Device application | signalling |
| Complementary | |
| Signalling function | status indication |
| Height | 56.5 mm |
| Auxiliary contact composition | 2 NO + 2 NC |
| Tightening torque | 0.6 N.m +/- 0.1 N.m |
| Auxiliary connection terminal | screw clamp terminal 0.05-2.6 mm² |
| Output voltage limits | AC: 250 V, DC: 30 V |
| Accessory / separate part category | signalling accessory |
| Mounting mode | plug-in |
| Maximum output current | 5 A |
| Local signalling | LED (green) for power available from mains |
| [Ie] rated operational current | 5 A at 30 V DC, 5 A at 250 V AC |
| Width | 20 mm |
| Depth | 69 mm |
| [Ui] rated insulation voltage | 300 V AC |
| Environment | |
| Pollution degree | 3 |
| IP degree of protection | IP20 |
| Contractual warranty | |
| Warranty | 18 |
