These accessories are straight terminal extensions for Compact NSX 100/160/250. These terminal extensions have anti-rotation ribs and can be attached to the standard terminals. The rated current is up to 250 A. These terminal extensions are supplied with flexible interphase barriers for insulation reinforcement. They are sold by set of 2 parts.
Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Mounting position | straight |
| Quantity per set | 2 |
| Poles description | 2P |
| Range | ComPacT |
| Product or component type | terminal extension |
| Accessory / separate part category | connection accessory |
| Range compatibility | ComPact ComPacT NSX DC PV NSX250 DC PV, ComPact ComPacT NSX DC PV NSX160 DC PV, ComPact ComPacT NSX DC PV NSX100 DC PV |
| Breaking capacity code | S |
| Range of product | ComPact NSX100...250 DC PV, ComPacT NSX100...250 DC PV new generation |
| Complementary | |
| [In] rated current | 250-250 A |
| Connection pitch | 35 mm |
