Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Mechanical durability | 0.5 Mcycles |
| Device short name | LA4EM |
| Product compatibility | LC1F2600 |
| Input voltage limits | 11...30 V on-state for PLC input, 0...5 V off-state for PLC input |
| Maximum operating rate | 600 cyc/h 55 °C |
| Input compatibility | PLC 24 V DC conforming to IEC 61131-2 Type 2 |
| Installed device | LXEFL2502 |
| Range | TeSys |
| Product or component type | electronic control module |
| Range compatibility | TeSys TeSys F LXEFL specific contactor coil, TeSys TeSys F LC1F contactor |
| Control circuit type | DC, AC at 50/60 Hz |
| Range of product | TeSys F |
| [Uc] control circuit voltage | 100...250 V DC, 100...250 V AC 50/60 Hz |
| Complementary | |
| Heat dissipation | 16-20 W |
| Hold-in power consumption in VA | 21.1-24.5 VA 50/60 Hz cos phi 0.5 (at 20 °C) |
| Inrush power in W | 1300-2400 W (at 20 °C) |
| Coil technology | built-in bidirectional peak limiting |
| Inrush power in VA | 1100-2300 VA 50/60 Hz cos phi 0.5 (at 20 °C) |
| Connections - terminals | control circuit: removable screw terminal block 1 cable(s) 0.2-2.5 mm² solid, control circuit: removable screw terminal block 1 cable(s) 0.25-2.5 mm² flexible with cable end, control circuit: removable screw terminal block 1 cable(s) 0.2-2.5 mm² flexible without cable end |
| Hold-in power consumption in W | 14-18 W at 20 °C |
| Tightening torque | 0.5...0.6 N.m for control circuit |
| Control circuit voltage limits | drop-out: 0...51 V DC (at 55 °C), drop-out: 0...65 V AC 50/60 Hz (at 55 °C), operational: 85...275 V AC/DC (at 55 °C) |
| Environment | |
| Net weight | 0.19 kg |
