TeSys Deca instantaneous auxiliary contact block with dust and damp protected contacts, for LC1D contactors and CAD control relays in harsh industral environments. It provides 2NO protected contacts rated up to 0.1A 125V AC / 30V DC, 4 earth terminals for cable screen continuity, connection by screw clamp terminals. Very low minimum switching capacity (5V / 1mA) thanks to gold alloy contact material. Front mounting by clip-on, it procures high reliability and durability. Multi standards certified (IEC, UL, CSA, CCC, EAC).
Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Device short name | LA1 |
| Auxiliary contacts operation | instantaneous |
| Range | TeSys |
| Range of product | TeSys Deca |
| [Ie] rated operational current | 0.1 A |
| [Ui] rated insulation voltage | 250 V conforming to IEC 60947-5-1 |
| Pole contact composition | 2 NO (sealed), 2 earth screen continuity poles |
| Mounting location | front |
| Product name | TeSys Deca |
| Product or component type | auxiliary contact block |
| Range compatibility | TeSys Deca LC1D, TeSys Deca CAD, TeSys F CR1F, TeSys F LC1F, TeSys D LC1D, TeSys D CAD |
| [Ue] rated operational voltage | 30 V DC for protected contact, 125 V AC for protected contact |
| Standards | GB/T 14048.5, CSA C22.2 No 60947-5-1, UL 60947-5-1, EN/IEC 60947-5-1 |
| Product certifications | UKCA, EAC, CCC, CSA, UL, CB |
| Complementary | |
| Quantity per set | set of 2 |
| Compatibility code | LA1 |
| Mechanical durability | 5 Mcycles |
| Tightening torque | 1.7 N.m - with screwdriver pozidriv No 2, 1.7 N.m - with screwdriver Philips No 2, 1.7 N.m - with screwdriver flat Ø 6 mm |
| Minimum switching voltage | 5 V |
| Connections - terminals | screw clamp terminals 2 cable(s) 1-2.5 mm²rigid, screw clamp terminals 1 cable(s) 1-2.5 mm²rigid, screw clamp terminals 2 cable(s) 1-2.5 mm²flexible without cable end, screw clamp terminals 2 cable(s) 1-2.5 mm²flexible with cable end, screw clamp terminals 1 cable(s) 1-2.5 mm²flexible without cable end, screw clamp terminals 1 cable(s) 1-2.5 mm²flexible with cable end |
| Height | 48 mm |
| Shielding continuity terminal | with |
| Depth | 39 mm |
| Width | 44 mm |
| Net weight | 0.04 kg |
| Insulation resistance | > 10 MOhm |
| Minimum switching current | 1 mA |
| Environment | |
| Protective treatment | TH conforming to IEC 60068 |
| Environmental characteristic | harsh environment |
| Ambient air temperature for storage | -25-70 °C |
| IP degree of protection | IP2X conforming to IEC 60529 |
| Ambient air temperature for operation | -25-70 °C |
