Trip unit TM160G DC, ComPacT NSX160 DC, 3 poles, thermal magnetic protections, generator protection, 160A rating

Home
/ MCCB and Switches
/ ComPacT for DC networks, new generation
/ Trip unit TM160G DC, ComPacT NSX160 DC, 3 poles, thermal magnetic protections, generator protection, 160A rating

Previous Product

Next Product

Trip unit TM160G DC, ComPacT NSX160 DC, 3 poles, thermal magnetic protections, generator protection, 160A rating

Schneider Electric green signature style for the entire ComPacT range

Estimated 40% reduction of wiring time for panel builders

Experience easier installation thanks to a new ergonomic front-plate design

Gain the confidence that all auxiliaries are on the right spot, and check that you have the right coil rating

Ergonomic new toggle for easier breaker manual operation

Manufacturer: Schneider Electric

SKU: C163MG160D

GTIN: 3606481055330

User guide

Environmental Disclosure

Instruction sheet

Full Description

TM160G is a 3 poles 3d thermal-magnetic trip unit used on ComPacT NSX 100/160/250 circuit breakers. This 160A rating thermal-magnetic trip unit is an optimum choice for generator protection applications. It embeds an adjustable thermal overload protection and a fixed magnetic protection against short-circuits. The rated current is 160A and the operational voltage is 750VDC. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications.

Old price: $163.68 inc GST

Price: $109.52 inc GST
