Head for pilot light, Harmony 9001K, metal, without cap, 30mm, 380...480V
Manufacturer: Schneider Electric
SKU: 9001KP5
GTIN: 785901005704
"This product is part of the Harmony 9001K range, an offer of Ø 30mm metal pushbuttons, switches and pilot lights." "This pilot light transformer has round screw head with normal operating mode." "It is a light block transformer with rated supply voltage of 380V/480V AC and a frequency of 50Hz/60Hz." "It has a round screw head." "It is a NEMA 1/2/3/3R/4/6/12/13 rated product." "This transformer is fitted with chromium plated metal bezel." "It is ideal for petrochemical, metallurgy, mining, oil and gas applications. It is also suitable for automotive, water and wastewater treatment applications." "This product is certified by CE, CSA LR25490 class 3211 03 and UL listed file E42259 CCN NKCR." "It is installed into a Ø 30mm panel cutout." "A comprehensive range of illuminated pushbuttons, pilot lights, emergency stop buttons, selector switches, joystick controllers and accessories to fit your needs." "The modular range of Ø 30mm metal control and signaling provides robust and reliable solutions for a wide range of heavy industry applications."
Old price: $293.15 inc GST
$178.35 inc GST
Supported cards
Supported cards

Products specifications

Attribute name Attribute value
Main
Range of product Harmony 9001K
Product or component type head for pilot light
Device short name K
Complementary
[Us] rated supply voltage 380...480 V
Light source incandescent bulb
Light block supply via transformer 380 V AC 50/60 Hz, via transformer 480 V AC 50/60 Hz, via integral transformer
Mounting diameter 30 mm
Operating mode normal
Cap/operator or lens colour without cap
Size 30 mm
Bezel material metal
Shape of screw head round
Supply frequency 50...60 Hz
Bulb base BA 9s
Environment
Product certifications CE, CSA LR25490 class 3211 03, UL listed file E42259 CCN NKCR
NEMA degree of protection NEMA 3R/6/13
Contractual warranty
Warranty 18
