This light block with integral resistance provides clear visual feedback on the status of your machines It is clearly distinguishable visually at a distance due illumination via integral LED, enabling complex machine statuses to be read at a glance It works at a rated voltage of 120V. It is impact resistant, dust resistant, and vibration resistant thanks to its IP20, making it ideal for operation in harsh environments
Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Bulb base | BA 9s |
| Device short name | 9001K |
| Product or component type | light block |
| Light block supply | direct via integral resistance |
| Range of product | Harmony 9001SK, Harmony 9001K |
| Complementary | |
| [Us] rated supply voltage | 120 V AC/DC, 120 V |
| Compatibility code | 9001K |
| Size | 30 mm |
| Net weight | 0.05 kg |
| Light block supply | full voltage or resistor |
| Light source | incandescent bulb |
| Environment | |
| Protective treatment | TC |
| Electrical shock protection class | class II conforming to IEC 61140 |
| Ambient air temperature for storage | -40-70 °C |
| IP degree of protection | IP20 conforming to IEC 60529 |
| Vibration resistance | 7 gn (f= 2-500 Hz) conforming to IEC 60068-2-6 |
| Shock resistance | 50 gn conforming to IEC 60068-2-27 |
| Standards | JIS C 4520, JIS C 852, CSA C22.2 No 14, IEC 60947-1, IEC 60947-5-4, UL 508, IEC 60947-5-1 |
| Ambient air temperature for operation | -25-70 °C |
| Product certifications | UL 508, NEMA |
