STP Series telescopic pipe temperature sensor, STP660, probe 100-300 mm, Satchwell compatible

Manufacturer: Schneider Electric

SKU: 5126080000

GTIN: 7332552012600

Catalog

Old price: $153.56 inc GST

Price: $203.08 inc GST

Qty:

Supported cards

Full Description
Specifications
Reviews

Temperature measurement is given through use of a passive thermistor output suitable for connection to the appropriate controller system type. It is intended for immersion mounting in pipe systems with a separate pocket/well, and has an extendable telescopic probe.

Products specifications

Attribute name	Attribute value
Main
IP degree of protection	IP65
Device application	pipe immersion
Depth	45 mm
Colour	black and green
Output type	resistive output
Width	85 mm
Sensor type	10 kOhm thermistor w/resistor & 11 kOhm Shunt temperature
Location	plant room
Product or component type	sensor
Type of measurement	temperature
Targeted region	Asia Pacific., Europe
Mounting support	pipe
Range of product	STP
Height	66 mm
Complementary
Measurement accuracy	0...25 °C +/- 0.3 °C
Diameter	6 mm probe:
Material	polyamide: enclosure
Length	100-300 mm for side probe
Environment
Product certifications	CE
Measurement range	- 10...120 °C
