Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Software name | Unity Pro > V2, ProWORX NxT > V2, ProWORX 32 > V2, Concept > V2 |
| Range of product | Modicon Quantum automation platform |
| Product or component type | ASCII serial link module |
| Complementary | |
| Number of messages | 255 |
| Product compatibility | all Quantum CPU |
| Module format | standard |
| Message nesting | 8 levels |
| Addressing requirement | 12 input words, 12 output words |
| Bus current requirement | 300 mA |
| Maximum power dissipation in W | 2 W |
| Memory capacity | 32 kB RAM, 128 kB flash |
| Clock | with calendar clock |
| Mode of transmission | ASCII |
| Maximum cable distance between devices | <20 m |
| Transmission rate | 19.2 kbit/s |
| Number of port | 2 RS232C non isolated conforming to DIN 66020 |
| Product specific application | for standard applications |
| Net weight | 0.3 kg |
| Buffer size | 255 I bytes/255 O bytes |
| Message length | 127 characters + 1 checksum maximum |
| Electrical connection | 2 connectors SUB-D 9 |
| Environment | |
| Relative humidity | 95-95 % without condensation |
| Ambient air temperature for storage | -40-85 °C |
| Resistance to electromagnetic fields | 10 V/m 80...1000 MHz conforming to IEC 801-3 |
| Ambient air temperature for operation | 0-60 °C |
| Operating altitude | <= 5000 m |
