Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Discrete input number | 32 |
| Product or component type | dc discrete input modules |
| Range of product | Modicon Quantum automation platform |
| Complementary | |
| Input voltage | 60 V 1-5 mA DC, 48 V 2-15 mA DC, 24 V 6-30 mA DC, 12 V 5-10 mA DC |
| Module format | standard |
| Local signalling | 32 LEDs (green) for input status, 1 LED (green) for bus communication is present (Active) |
| Addressing requirement | 2 input words |
| Bus current requirement | 300 mA |
| Voltage state 1 guaranteed | 45...60 V 60 V - 15...20 %, 34...48 V 48 V - 15...20 %, 11...24 V 24 V - 15...20 %, 9...12 V 12 V +/- 5 % |
| Net weight | 0.295 kg |
| Voltage state 0 guaranteed | 0...5 V 24 V - 15...20 %, 0...12.5 V 60 V - 15...20 %, 0...10 V 48 V - 15...20 %, 0...1.8 V 12 V +/- 5 % |
| Input voltage limits | 10...60 V |
| Marking | CE |
| Isolation between group | 700 Vrms DC for 1 minute |
| Response time | 4 ms from state 1 to state 0, 4 ms from state 0 to state 1 |
| Absolute maximum voltage | 75 V |
| Isolation between group and bus | 2500 Vrms DC for 1 minute |
| Group of channels | 4 |
| Switching frequency | <= 100 Hz |
| Power dissipation | 1 W + (0.25 x number of points on) |
| Logic input | positive (sink) |
| Environment | |
| Operating altitude | <= 5000 m |
| Resistance to electrostatic discharge | 8 kV on air conforming to IEC 801-2, 4 kV contact conforming to IEC 801-2 |
| Relative humidity | 95-95 % without condensation |
| Ambient air temperature for storage | -40-85 °C |
| Standards | UL 508, CSA C22.2 No 142, EN/IEC 61131-2 |
| Resistance to electromagnetic fields | 10 V/m 80-2000 MHz conforming to IEC 801-3 |
| Ambient air temperature for operation | 0-60 °C |
| Product certifications | hazardous location class 1, division 2, CE, CSA, EAC, UL, Merchant Navy, RCM |
