| Attribute name | Attribute value |
|---|---|
| Main | |
| Device short name | ZB4 |
| Sale per indivisible quantity | 1 |
| Head type | standard |
| Type of operator | spring return |
| Range of product | Harmony XB4 |
| Operator profile | blue recessed, unmarked |
| Bezel material | chromium plated metal |
| Shape of signaling unit head | round |
| Product or component type | head for non-illuminated push-button |
| Mounting diameter | 22 mm |
| Operator additional information | high guard |
| Complementary | |
| Group of product | recessed push |
| Compatibility code | ZB4 |
| Mechanical durability | 10000000 cycles |
| Device presentation | basic element |
| CAD overall height | 29 mm |
| Customizable | 1, no |
| Electrical composition code | C15 for <1 contacts using single blocks in front mounting, C11 for <3 contacts using single blocks in front mounting, C2 for <9 contacts using single and double blocks in front mounting, C1 for <9 contacts using single blocks in front mounting |
| Main group | push-button |
| CAD overall depth | 31 mm |
| CAD overall width | 29 mm |
| Marking | unmarked |
| Cap/operator or lens colour | blue |
| GCR BRIDGE | ZB4BACUST02 |
| Environment | |
| Protective treatment | TH |
| Ambient air temperature for storage | -40-70 °C |
| IP degree of protection | IP69K, IP69, IP67, IP66 conforming to IEC 60529 |
| Ambient air temperature for operation | -40-70 °C |
| IK degree of protection | IK06 conforming to IEC 50102 |
| NEMA degree of protection | NEMA 4X, NEMA 13 |
| Overvoltage category | class I conforming to IEC 60536 |
| Vibration resistance | 5 gn (f= 2-500 Hz) conforming to IEC 60068-2-6 |
| Shock resistance | 50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27, 30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27 |
| Standards | JIS C8201-1, EN/IEC 60947-5-4, CSA C22.2 No 14, JIS C8201-5-1, EN/IEC 60947-1, UL 508, EN/IEC 60947-5-1, EN/IEC 60947-5-5 |
| Product certifications | DNV, CSA, BV, GL, LROS (Lloyds register of shipping), UL listed |
