Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Safety use category | SIL 3 conforming to EN/IEC 61508, performance level e conforming to EN/ISO 13849-1, category 4 maximum conforming to EN 954-1 |
| Safety module application | power supply |
| Safety module name | XPS MF60 |
| Product or component type | Preventa safety PLC power supply |
| Standards | DIN V 19250, EN 50156 pending, DIN V 0801, IEC 61131 |
| Range of product | Preventa Safety automation |
| [Us] rated supply voltage | 24 V DC - 15...20 % |
| Complementary | |
| Associated fuse rating | 32 A |
| Connections - terminals | removable screw clamp terminals, 2 x 0.75...2 x 6 mm² (AWG 19) solid without cable end, removable screw clamp terminals, 2 x 0.75...2 x 6 mm² (AWG 19) flexible without cable end, removable screw clamp terminals, 1 x 0.75...1 x 16 mm² (AWG 19) solid without cable end, removable screw clamp terminals, 1 x 0.75...1 x 16 mm² (AWG 19) flexible without cable end, removable screw clamp terminals, 2 x 0.5...2 x 6 mm² (AWG 20) flexible with cable end, removable screw clamp terminals, 2 x 0.5...2 x 4 mm² (AWG 20) flexible without cable end, removable screw clamp terminals, 1 x 0.75...1 x 6 mm² (AWG 20) flexible without cable end, removable screw clamp terminals, 1 x 0.75...1 x 6 mm² (AWG 20) flexible with cable end |
| Net weight | 0.82 kg |
| Supply | SELV or PELV conforming to EN/IEC 60950 |
| Current consumption | 30 A at 24 V DC power supply |
| Output voltage | 5 V DC / 2 A, 3.3 V DC / 10 A |
| Environment | |
| Operating altitude | < 2000 m |
| Electrical shock protection class | class II conforming to IEC 61131-2 |
| Resistance to electrostatic discharge | 8 kV on air conforming to EN/IEC 61000-4-2, 4 kV contact conforming to EN/IEC 61000-4-2 |
| Relative humidity | 95-95 % supply not connected |
| Ambient air temperature for storage | -40-85 °C conforming to EN/IEC 61131-2 |
| Electromagnetic compatibility | EN/IEC 61131-2 |
| IP degree of protection | IP20 (with covering plate on unused in rack I/O card slots) |
| Shock resistance | 15 gn for 11 ms (2 cycles per axis) conforming to EN 61131-2 |
| Vibration resistance | 1 gn (f = 10-150 Hz) - 10 cycles per axis - conforming to EN 61131-2 |
| Ambient air temperature for operation | 0-60 °C |
| Pollution degree | 2 |
| Immunity to microbreaks | 10 ms |
| Resistance to electromagnetic fields | 10 V/m (26-1000 MHz), amplitude modulation 80 % conforming to EN/IEC 61000-4-3 |
