Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Function of module | monitoring safety dialogue, monitoring safety actuators |
| Safety use category | SIL 3 conforming to EN/IEC 61508, performance level e conforming to EN/ISO 13849-1, category 4 maximum conforming to EN 954-1 |
| Safety module application | extension of I/O capacity |
| Safety module name | XPSMF2 |
| Structure type | 10BASE-T/100BASE-TX |
| Supply | SELV or PELV conforming to EN/IEC 60950 |
| Product or component type | Preventa safety remote output relay module |
| Number of outputs | 8 relay |
| Range of product | Preventa Safety automation |
| [Us] rated supply voltage | 24 V DC - 15...20 % |
| Complementary | |
| Maximum switching capacity in W | <35 / 70 V for relay output, <30 / 127 V for relay output, <90 / 30 V for relay output |
| Depth | 86.5 mm |
| Width | 207 mm |
| Response time | depending on size of application |
| Mechanical durability | 1000000 cycles for relay output |
| Switching current capacity | 3 A / 100 A with internal fuse relay output |
| Output type | relay, 2 NO per output circuit(s), volt-free |
| Communication port protocol | safe Ethernet with 2 RJ45 port(s), transmission rate: 100 Mbps, 10 Mbps, medium: dual twisted pair cable, category 5D or better |
| Minimum switching voltage | 5 V 250 V DC output relay, 5 V 250 V AC output relay |
| Net weight | 1.3 kg |
| Associated fuse rating | 10 A, slow-blow |
| Current consumption | 0.6 A at 24 V DC on power supply |
| Exchange mode | half duplex, full duplex, autonegotiation |
| Electrical durability | 250000 cycles for relay output |
| Contacts material | silver alloy (Ag/Ni) for relay output |
| Mounting support | 35 mm symmetrical DIN rail |
| Height | 109 mm |
| Maximum switching capacity in VA | <240 VA, cos f = 0.5-0.5 for relay output |
| Number of terminal blocks | 8 for relay output, 1 for power supply |
| Environment | |
| Ambient air temperature for storage | -40-85 °C |
| IP degree of protection | IP20 |
| Ambient air temperature for operation | 0-60 °C |
