This product is part of the Lexium 28 range, an offer of motion servo drives and servo motors. This is a shielded power cordset for BCH2 motors without brake. It is equipped with a Molex 4-pin connector (servo motor side) and an open end (servo drive side). The power cable's shield serves as electromagnetic compatibility protection. the AWG gauge of the cable is 4x AWG 18. It measures 5m long and weighs 0.45kg. It is a connection accessory to the BCH2 servo motors. It is compatible with servo motors type BCH2MBA53, /MB013, /LD023, /LD043, /LF043, /HF073, /LF073. It plugs into the power connector of BCH2 servo motors. Lexium 28 servo drives and Lexium BCH2 servo motors are Optimized servo bundles for compact machines. Designed for optimized & cost-effective.
Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Accessory / separate part destination | between servo motor and servo drive |
| Accessory / separate part type | preassembled power cordset |
| Range compatibility | Lexium 28 |
| Product or component type | power cable |
| Accessory / separate part category | connection accessory |
| Cable length | 5 m |
| Product compatibility | servo motor BCH2 at 750 W (80 mm) (without brake), servo motor BCH2 at 400 W (80 mm) (without brake), servo motor BCH2 at 400 W (60 mm) (without brake), servo motor BCH2 at 200 W (60 mm) (without brake), servo motor BCH2 at 100 W (40 mm) (without brake), servo motor BCH2 at 50 W (40 mm) (without brake) |
| Range of product | Lexium 28 |
| Complementary | |
| AWG gauge | 4 x AWG 18 |
| Net weight | 0.45 kg |
| Electrical connection | connector - Molex 4-pin for servo motor side, free end for servo drive side |
