Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Thermal losses | 8 W |
| Range compatibility | Altivar Machine ATV340 |
| [In] rated current | 50 A |
| Product specific application | radio interference input filter |
| Mounting location | at variable speed drive side |
| Network number of phases | three phase |
| Product or component type | EMC input filter |
| Product compatibility | variable speed drive ATV340 motor: 11 kW, 380...480 V, variable speed drive ATV340 motor: 15 kW, 380...480 V |
| Range of product | Altivar |
| Complementary | |
| Depth | 170 mm |
| Width | 90 mm |
| Electrical connection | terminal 16 mm² AWG 4 |
| Network rated voltage | 380-480 V |
| Earth leakage current | 7.6 mA at 400 V 50 Hz TN |
| Net weight | 5.2 kg |
| Maximum motor cable length | 50 m shielded motor cable 4 kHz conforming to IEC 61800-3 category C2, 380...480 V, 100 m shielded motor cable 4 kHz conforming to IEC 61800-3 category C3, 380...480 V |
| Tolerance | 10 % |
| Height | 285 mm |
| Mechanical robustness | vibrations class 3M4 conforming to IEC 60721-3-3, shocks class 3M4 conforming to IEC 60721-3-3 |
| Environment | |
| Operating altitude | 1000...4000 m with current derating 1 % per 100 m, 0...1000 m without current derating |
| IP degree of protection | IP20mounting side by side |
| Relative humidity | 5-95 % without condensation conforming to IEC 61800-5-1 |
| Ambient air temperature for storage | -40-70 °C |
| Ambient air temperature for operation | 50-60 °C (with current derating 1.5 % per °C), -10-50 °C (without current derating) |
| Standards | IEC 61800-3 |
