The VG310 is a high pressure (PN16) 3-way flanged globe valve for a wide range of heating and cooling applications. The valve use a stainless steel plug for high close off pressures with a low actuator force. Stainless Steel plug and seat provides a high pressure differential capability and a low leakage. The crown plug provides precise fluid control with a rangeability of 100:1 and is of a self cleaning design for reliable operation. Valve size: DN50, Rp 2 thread, Flow capacity, Kvs: 35 m³/h. Constructed and flanged to a PN16 pressure class. PTFE Seals provide a working temperature range of -7 °C to 137 °C. 11 mm stroke ensures high controllability, Equal percentage flow characteristic ensures high controllability at low opening degrees.
Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Operating fluid temperature | -7-135 °C |
| Body material | CDA 83450 Oshalloy, ASTM B584, bronze |
| Satured steam pressure delta P | 35 psi |
| Saturated steam temperature | -7-135 °C |
| Seating seal material | Port B:brass, Port A:EPDM (ethylene propylene diene monomer) |
| Seat leakage | Port A: Class IV-S1 (0.005 %) (Ports A-AB), Port A: Class III (0.1 %) (Ports B-AB) |
| Product or component type | valve |
| Targeted region | Australia., Asia Pacific., Europe |
| Valve connection size | Rp 2 |
| Seat material | Port B: bronze, Port A: bronze |
| Valve product range | Venta |
| Medium compatibility | Water, Steam, Glycol 60 %, Glycol 50 %, Glycol 30 %, Glycol 25 % |
| Control valve rangeability | greater than 100:1 |
| Plug material | Brass UNS C36000 |
| Valve product series | VG310R |
| Flow coefficient | 35 kvs, 40.47 cv |
| Stem flow action | Stem up closes A and opens B to AB |
| Valve configuration | 3-Way |
| Stem movement | linear |
| Pressure fluid max delta P normal life | 58 psi |
| Valve type | globe |
| Valve model | VG210R 50B 35E SU00 |
| Packing material | PTFE/EPDM chevrons |
| Valve connection type | Rp Internal |
| Stem seal material | PTFE (polytetrafluoroethylene), EPDM (ethylene propylene diene monomer) |
| Flow characteristic | equal percentage |
| Trim material | brass |
| Stroke length | 11 mm |
| Stem material | stainless steel 316Ti |
| Pipe size | 50 mm |
| Pressure class | PN16 |
| Body size | 50 mm (2 in) |
