Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Discrete output number | 8 |
| Discrete output voltage | 24...120 V DC conforming to EN/IEC 61131-2 19...143 V |
| Product or component type | discrete output module |
| Range of product | Modicon Premium Automation platform |
| Discrete output type | relay protected |
| Complementary | |
| Module format | standard |
| Short-circuit protection | 6.3 A, interchangeable fuse per common fast blow |
| Contacts type and composition | 2 x 2 C/O + 2 x 2 NO |
| Electrical durability | 2000000 cycles DC-3 50 W 48 V inductive, 2000000 cycles DC-3 20 W 24 V inductive, 2000000 cycles DC-3 110 W 100...120 V inductive, 1000000 cycles DC-3 50 W 24 V inductive, 1000000 cycles DC-3 220 W 100...120 V inductive, 1000000 cycles DC-3 100 W 48 V inductive, 1000000 cycles DC-12 50 W 24 V resistive, 1000000 cycles DC-12 220 W 100...120 V resistive, 300000 cycles DC-12 440 W 100...120 V resistive, 300000 cycles DC-12 200 W 48 V resistive, 300000 cycles DC-12 100 W 24 V resistive, 1000000 cycles DC-12 100 W 48 V resistive |
| Net weight | 0.37 kg |
| [Ith] conventional free air thermal current | 5 A |
| Response time | < 15 ms (deactivation), < 10 ms (activation) |
| Output overvoltage protection | RC circuit and Ge-Mov |
| Marking | CE |
| Output overload protection | 6.3 A, interchangeable fuse per common fast blow |
| Current consumption | 80 mA at 24 V DC rack, 55 mA at 5 V DC |
| Insulation resistance | > 10 MOhm 500 V |
| Electrical connection | screw terminal block |
| Power dissipation | (0.25 W + 0.24 W x No of outputs at state 1) |
| Environment | |
| Operating altitude | 0...2000 m |
| IP degree of protection | IP20 |
| Protective treatment | TC |
| Relative humidity | 5-95 % without condensation for storage, 10-95 % without condensation for operation |
| Ambient air temperature for storage | -25-70 °C |
| Dielectric strength | 2000 V 50/60 Hz 60 s |
| Pollution degree | 2 |
| Standards | CSA C22.2 No 213 Class I Division 2 Group A, IEC 61131-2, 93/68/EEC, CSA C22.2 No 142, CSA C22.2 No 213 Class I Division 2 Group D, 73/23/EEC, CSA C22.2 No 213 Class I Division 2 Group B, 92/31/EEC, CSA C22.2 No 213 Class I Division 2 Group C, UL 508, 89/336/EEC |
| Ambient air temperature for operation | 0-60 °C |
| Product certifications | RMRS, ABS, BV, RINA, DNV, GL, LR |
