Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Discrete input number | 32 current sink isolated conforming to EN/IEC 61131-2 type 2 |
| Discrete input current | 7 mA |
| Sensor power supply | 38-60 V |
| Input compatibility | with 2-wire/3-wire proximity sensors conforming to EN/IEC 60947-5-2 |
| Product or component type | discrete input module |
| Discrete input voltage | 48 V DC positive |
| Range of product | Modicon Premium Automation platform |
| Complementary | |
| Module format | standard |
| Electrical connection | HE-10 connector |
| Response time | <= 7 ms, 4 ms |
| Current state 0 guaranteed | <= 2 mA |
| Voltage state 1 guaranteed | >= 30 V |
| Voltage state 0 guaranteed | <= 10 V |
| Net weight | 0.31 kg |
| Current state 1 guaranteed | >= 6.5 mA |
| Marking | CE |
| Insulation resistance | < 10 MOhm 500 V DC |
| Current consumption | 275 mA at 24 V DC, 140 mA at 5 V DC |
| Power dissipation | (2 W + 0.1 W x No of channels used) |
| Input impedance | 6300 Ohm at state 1 |
| Environment | |
| Operating altitude | 0...2000 m |
| IP degree of protection | IP20 |
| Protective treatment | TC |
| Relative humidity | 5-95 % without condensation for storage, 10-95 % without condensation for operation |
| Ambient air temperature for storage | -25-70 °C |
| Dielectric strength | 1500 V AC at 50/60 Hz |
| Pollution degree | 2 |
| Standards | EN/IEC 61131-2, CSA C22.2 No 142, CSA C22.2 No 213 Class I Division 2 Group C, 89/336/EEC, 93/68/EEC, UL 508, CSA C22.2 No 213 Class I Division 2 Group B, CSA C22.2 No 213 Class I Division 2 Group A, CSA C22.2 No 213 Class I Division 2 Group D, 92/31/EEC, IEC 60664, 73/23/EEC |
| Ambient air temperature for operation | 0-60 °C |
| Product certifications | RINA, DNV, LR, RMRS, BV, ABS, GL |
