Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Radio power | 37 dBm |
| Product or component type | remote radio |
| Transmission rate | 12.5 kHz at < = 4.8 kbit/s, 25.0 kHz at < = 9.6 kbit/s |
| Power range | 2.4 W: receive, 21 W: transmit |
| Range of product | Trio Licensed Radios |
| Network frequency | 395...470 MHz (M-Band) |
| Complementary | |
| Net weight | 0.32 kg |
| Length | 154.0 mm |
| Width | 29.0 mm |
| Channel access management | channelshare collision avoidance |
| Exchange mode | half duplex |
| Connector type | power supply: 1.0 x screw terminal (2.0 poles) |
| Mounting support | direct mounting, DIN rail |
| Modulation Technique | GMSK |
| Height | 102.0 mm |
| Function available | diagnostic via TVIEW software, configuration via TVIEW software |
| Integrated connection type | antenna, N socket, 1 serial port, DE-9 RS232/RS485, 300...115200 bps |
| Input voltage | 10...16 V DC |
| Environment | |
| IP degree of protection | IP41 |
| Housing material | die cast aluminium |
| Relative humidity | 5-95 % 40 °C |
| Standards | CSA C22.2 No 213 Class I Division 2 Group D, CSA C22.2 No 213 Class I Division 2 Group C, CSA C22.2 No 213 Class I Division 2 Group B, CSA C22.2 No 213 Class I Division 2 Group A, RSS GEN, RSS 119, RSS 102, FCC CFR 47 part 90, FCC CFR 47 part 15 |
| Ambient air temperature for storage | -40-85 °C |
| Ambient air temperature for operation | -40-70 °C |
