The Security Expert SX Mullion reader provides a complete multi-technology smart card RFID solution. It is compatible with all Wiegand capable control systems and incorporating RS-485 communication. Security Expert card readers allow rapid deployment of secure technology in any environment. This reader is white and equipped with a keypad. It is compatible with 13.56 MHz and Bluetooth wireless technology. Dimensions are 117 mm (4.61") in height, 46 mm (1.81") in width and 18 mm (0.71") in depth. This product is certified RSM, RCM, AS/NZS 2201.1 Class 5, CE, UKCA, UL/ULC, ICES-003, FCC, OSDP. This model is suited for mullion-mount.
Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Depth | 18 mm |
| Width | 45 mm |
| [In] rated current | 130 mA |
| Technology type | RFID |
| Ambient air temperature for storage | -10-85 °C |
| Colour | black |
| Mounting mode | wall-mounted |
| Net weight | 110 g |
| Product or component type | access control card reader |
| Standards | CAN/ULC-S319-05, EN 50131-6:2008, EN 50131-3:2009, EN 50131-1:2006, UL 294, ICES-003, FCC CFR 47 part 15:class A |
| Communication port protocol | Bluetooth, RS485, Wiegand |
| Maximum cable distance between devices | 150 m |
| Height | 115 mm |
| Ambient air temperature for operation | -35-65 °C |
| [Us] rated supply voltage | 9.5...14 V DC |
| Product certifications | CE, RCM |
