This input kit is part of the Modicon STB range, an offer of modular distributed I/O. This basic digital input kit is an accessory kit for Programmable Logic Controllers (PLC) and Programmable Automation Controllers (PAC). The kit has 4 digital inputs. Setting can be done via Advantys STB configuration software. It weighs 0.11kg. It is suitable for packaging, bottling, assembly, distribution, textile, printing and semiconductor machines applications. These islands can be used to connect TeSys U or TeSys T motor starters, Altivar speed drives, encoders, Harmony HMI, etc. The kit includes STBXBA1000 base, STBDDI3425 module, STBXTS2100 6-terminal spring clamp connector, and STBXTS1100 6-terminal screw type connector. The Modicon STB distributed I/O solution is an open, modular input/output system that makes it possible to design automation islands managed by a primary controller via a bus or communication network.
Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Range of product | Modicon STB distributed I/O solution |
| Kit composition | STBXTS1100, 6-terminal screw type connector, STBXTS2100, 6-terminal spring clamp connector, STBDDI3425 module, STBXBA1000 base |
| Discrete input number | 4 |
| Product or component type | basic digital input kit |
| Discrete input voltage type | DC |
| Discrete input voltage | 24 V |
| Complementary | |
| Product compatibility | power distribution module STBPDT3100/3105, I/O base STBXBA1000 |
| Discrete input logic | positive |
| Input voltage limits | -3...5 V at state 0, 11...30 V at state 1 |
| Current state 1 guaranteed | >= 2.5 mA |
| Marking | CE |
| Protection type | reverse polarity protection, input protection resistor-limited, power protection integrated fuse on PDM time lag 5 A |
| Permissible voltage | 30 V |
| Hot swapping fallback | yes for basic NIMs |
| Status LED | 1 LED per channel (green) channel status (IN1 to IN4), 1 LED (green) module status (RDY) |
| Current supplied by sensor | 50 mA per channel |
| Height | 18.4 mm |
| Cold swapping | yes |
| Insulation between channels and logic bus | 1500 V for 1 minute |
| Input filtering | 3 ms |
| [Us] rated supply voltage | 24 V DC |
| Depth | 65.1 mm |
| Overvoltage category | II |
| Width | 125 mm |
| Response time | 3.8 ms on-to-off, 3.5 ms off-to-on |
| Net weight | 0.111 kg |
| Current state 0 guaranteed | <= 1.2 mA |
| Discrete input current | 8 mA |
| Current consumption | 45 mA at 5 V DC for logic bus |
| Supply | power distribution module |
| Absolute maximum voltage | 56 V 1.3 ms |
| Environment | |
| Ambient air temperature for operation | 32...140 °F without derating, 0-60 °C (without derating) |
| Relative humidity | 95-95 % at 60-60 °C without condensation |
| Ambient air temperature for storage | -40-85 °C without derating, -40...185 °F without derating |
| Pollution degree | 2 conforming to IEC 60664-1 |
| IP degree of protection | IP20 conforming to IEC 61131-2 class 1 |
| Operating altitude | <= 2000 m |
| Vibration resistance | +/-0.35 mm at 10-58 Hz, 5 gn at 58-150 Hz on 35 x 15 mm symmetrical DIN rail, 3 gn at 58-150 Hz on 35 x 7.5 mm symmetrical DIN rail |
| Shock resistance | 30 gn for 11 ms conforming to IEC 88 reference 2-27 |
| Standards | IEC 61131-2 Type 1 |
| Product certifications | CSA, FM Class 1 Division 2, UL |
