Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| [Us] rated supply voltage | 220...240 V AC at 50/60 Hz |
| Device short name | ACP + UA |
| Range compatibility | MasterPact NT |
| Mounting location | external |
| Net weight | 4.85 kg |
| Product or component type | automatic controller |
| Accessory / separate part category | interlocking accessory |
| Range of product | MasterPact NW |
| Complementary | |
| Local signalling | fault trip, off, on |
| Test function | by pressing the test button on the front of the controller |
| Input type | contacts customer voluntary order to transfer to source R |
| Compatibility code | ACP+UA |
| [Ie] rated operational current | DC-13: 2 A 24 V, DC-12: 8 A DC 24 V, DC-12: 2 A DC 48 V, DC-12: 0.6 A DC 110 V, AC-13: 7 A AC 24 V, AC-13: 6 A AC 110 V, AC-12: 8 A AC 110 V, AC-12: 5 A AC 380/415 V, AC-12: 4 A AC 440 V, DC-12: 0.4 A DC 250 V, AC-15: 5 A AC 48 V, AC-15: 5 A AC 24 V, AC-15: 3 A AC 220/240 V, AC-14: 5 A AC 48 V, AC-14: 5 A AC 24 V, AC-14: 4 A AC 220/240 V, AC-13: 7 A AC 48 V, AC-13: 6 A AC 220/240 V, AC-15: 4 A AC 110 V, AC-14: 4 A AC 110 V, AC-12: 8 A AC 48 V, AC-12: 8 A AC 24 V, AC-12: 8 A AC 220/240 V |
| Selection modes | circuit breaker on N, circuit breaker on R |
| Output type | contacts customer: indication of operation in automatic or stop mode |
| Complementary function | additional contact: transfer to replacement source only if contact is closed, setting of maximum startup time for the replacement source, selection of type of normal source (single-phase or three-phase), forced normal source if replacement source not operational during peak-tariff, voluntary transfer to replacement source (e.g. energy management commands) |
| [Ith] conventional free air thermal current | 8 A |
| Interlocked device | MasterPact NT, MasterPact NW |
| Environment | |
| IP degree of protection | IP30 side: conforming to EN 60529, IP40 front: conforming to EN 60529, IP20 connectors: conforming to EN 60529 |
| Standards | IEC 947-5-1 |
| IK degree of protection | front: IK07 conforming to EN 50102 |
