Differential Air Pressure Trans: For the monitoring of air ducts, filters and fans, SPD310-100/300/500/1000Pa
Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Wiring technique | 3-wire |
| IP degree of protection | IP66 |
| Device application | pump and compressor monitoring |
| Controlled fluid | water |
| Location | plant room |
| Depth | 25 mm |
| Fitting type | male |
| Width | 25 mm |
| Type of measurement | gauge pressure |
| Fitting size | 1/4" NPT |
| Relative humidity | 0-95 % RH, non-condensing |
| Mounting support | pipe |
| Analogue output type | 4...20 mA |
| Calibration certificate | none |
| Height | 88 mm |
| Ambient air temperature for operation | -30-120 °C |
| Pressure measurement accuracy | +/- 0.25 % BFSL |
| [Us] rated supply voltage | 10...28 V DC |
| Pressure measurement range | 0...75 psi (0...5 bar) |
| Product certifications | CE |
