Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Enclosure nominal width | 500 mm |
| Device short name | PLAZ |
| Device application | multi-purpose |
| Enclosure nominal depth | 420 mm |
| Enclosure mounting | floor-standing |
| Range | Thalassa |
| Enclosure nominal height | 500 mm |
| Device composition | 1 plinth, 1 door, 1 rear panel, 2 side part, 1 bottom part, 1 top part |
| Product name | Thalassa PLA |
| Product or component type | suitable enclosure |
| Complementary | |
| Colour | grey (RAL 7035) |
| Material | polyester reinforced with fibreglass |
| Body type | sealed top and open bottom part assembled with side parts |
| Electrical insulation class | class II |
| Number of doors | 1 door(s) |
| Door opening side | reversible (120 °) |
| Lock type | 2 points handle lock, 5 mm double-bar |
| Door type | plain front |
| Standards | IEC 62208 |
| Removable parts | rear panel by fixing element, door by hinges |
| Accessibility for operation | rear, bottom, front |
| Product certifications | Veritas |
| Environment | |
| Fire resistance | 960 °C conforming to IEC 62208 |
| IP degree of protection | IP54 conforming to IEC 60529 (plinth type open bottom) |
| Ambient air temperature for storage | -35-90 °C |
| IK degree of protection | IK10 conforming to IEC 62262 (plain door) |
