| Attribute name | Attribute value |
|---|---|
| Main | |
| Device application | multi-purpose |
| Device composition | 1 fixing elements, 1 lamp |
| Product or component type | lamp |
| Accessory / separate part category | lighting accessory |
| Power factor | 0.9 |
| Range of product | Lighting and power sockets |
| Complementary | |
| Bulb base | integral LED |
| Width | 40 mm |
| Colour | black (RAL 9005) |
| Rated lamp wattage | 10 W |
| Service life in hours | 25000 h |
| [Ue] rated operational voltage | 120/230 V AC 50/60 Hz |
| Luminous flux | 950 lm |
| Bulb type | LED |
| Control type | built-it switch |
| Electrical connection | cable quick connector 1 m not supplied, cable quick connector 3 m not supplied |
| Length | 372 mm |
| Colour temperature | 4000 K |
| Outlet standard deviation | without socket |
| Material | PC (UL94 V-0) |
| Fixing mode | clip-in, screws, magnetic fixing |
| Range compatibility | Thalassa, Spacial |
| Mounting support | metal parts, DIN rail, bracket |
| Height | 63 mm |
| Environment | |
| Ambient air temperature for storage | -10-60 °C |
| Electrical insulation class | class II |
| IP degree of protection | IP20 conforming to IEC 60529 |
| Electromagnetic compatibility | EMC immunity conforming to EN 55015 |
| Standards | EN 55015, UL 508 A, UL 1598, IEC 60598, UL 94, UL 8750 |
| Ambient air temperature for operation | -16-65 °C |
