This Acti9 product is a 1-pole neutral bar. It has a screw terminals cable connection. The housing of the product is made of ceramic. It is suitable with iC60H circuit breaker. It has been designed to be installed into an Acti9 Isobar A and B type distribution boards. The le rated operational current is 250A. The Ue rated operational voltage is up to 415V. The product colour is grey (RAL 7016). The operating temperature is from -15°C to +50°C.
Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Range | Acti9 |
| Product or component type | neutral bar |
| Complementary | |
| Colour | grey (RAL 7016) |
| [Ie] rated operational current | 250 A at 415 V |
| Poles description | 1P |
| Protection device name | iC60H |
| Material | ceramic |
| Connections - terminals | screw terminals |
| Range compatibility | Acti 9 distribution board |
| Environment | |
| Ambient air temperature for operation | -15-50 °C |
