It is a MH Vigi add-on module for 4 poles Compact NSX 250 and EasyPact CVS 250. It provides an earth-leakage protection when installed directly on the device terminals. It directly actuates the trip unit in case of insulation fault. The addition of this Vigi add-on module does not modify Compact NSX 250 or EasyPact CVS 250 characteristics. It is a MH type module in 4 poles version, self-powered by the input voltage. The operational voltage for the Vigi add-on is from 440VAC to 550VAC 50/60Hz. The sensitivity is adjustable from 30mA to 10A, the time delay is also adjustable. The dimensions of the circuit breaker equipped with this module are 140mm x 236mm x 86mm.
Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Residual earth-leakage time delay adjustment type | adjustable 4 settings |
| Device application | wiring |
| Earth-leakage add-on module name | MH |
| Poles description | 4P |
| Residual earth-leakage sensitity adjustment type | adjustable 5 settings |
| Range | ComPacT |
| [Δt] residual earth-leakage time delay adjustment | 150-150 ms, 310-310 ms, 60-60 ms, 0-0 ms |
| Product or component type | Vigi add-on |
| Earth-leakage sensitivity | 10 A, 3 A, 1 A, 0.3 A, 0.03 A |
| Earth-leakage protection class | class A |
| Range compatibility | ComPact ComPact NSX250 circuit breaker |
| Range of product | ComPact NSX100...250 |
| [In] rated current | 250 A |
| Complementary | |
| Overvoltage category | class II |
| Maximum breaking time | 800 ms |
| Network type | AC |
| Earth-leakage protection | with |
| [Ue] rated operational voltage | 440...550 V AC 50/60 Hz conforming to IEC 60947-2 |
| Network frequency | 50/60 Hz |
| Environment | |
| Electrical shock protection class | class II |
| Standards | IEC 60947-2 |
