Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Poles description | 4 x 4P: fixed NG125 vertical installation, 5 x 3P: fixed NG125 vertical installation, 8 x 2P: fixed NG125 vertical installation, 16 x 1P: fixed NG125 vertical installation, 4P: fixed modular device vertical installation, 3P: fixed modular device vertical installation, 2P: fixed modular device vertical installation, 1P: fixed modular device vertical installation |
| Device application | modular distribution application |
| Type of rail | DIN |
| Range | Prisma |
| Product or component type | rail |
| Accessory / separate part category | installation accessory |
| Installed device | Multi9: clip-on modular device without earth leakage protection - control: toggle, Acti 9: clip-on modular device without earth leakage protection - control: toggle, EasyPact: TVS GZ1E <= 32 A - vertical installation, TeSys: GV2 <= 40 A - vertical installation, TeSys: LCE140 - vertical installation, TeSys: LC1D40 - vertical installation, Multi9: fixed NG125 without earth leakage protection - control: toggle - vertical installation |
| Range compatibility | Prisma Prisma iPM M framework |
| Range of product | Prisma iPM |
| Complementary | |
| Material | sheet metal |
| Length | useful: 432 mm |
| Number of vertical modules [50 mm] | 3 module(s): TVS GZ1E <= 32 A, direct in floor-standing enclosure, 3 module(s): GV2 <= 40 A, direct in floor-standing enclosure, 3 module(s): LCE140, direct in floor-standing enclosure, 3 module(s): LC1D40, direct in floor-standing enclosure, 5 module(s): NG125 without earth leakage protection, connection block in floor-standing enclosure, 4 module(s): NG125 without earth leakage protection, direct in floor-standing enclosure, 4 module(s): modular device, connection block in floor-standing enclosure, 3 module(s): modular device, direct in floor-standing enclosure |
| 9 mm pitches | 48 |
| Offer type | standard |
| Enclosure/cubicle description | floor-standing enclosure - width 600 mm |
| Environment | |
| Product certifications | ASEFA |
| Standards | IEC 61439-2 |
