TeSys Deca auxiliary contact block, for contactors LC1D, LC1F and control relays CAD. It provides 1NO+1NC contacts rated up to 10A 690V AC, On-delay setting range 10-180s Clip-on front mounting, it procures high reliability and durability. Multi standards certified (IEC, UL, CSA, CCC, EAC), Sustainability compliant.
Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Device short name | GVAED |
| Auxiliary contacts operation | fault signal 1 NO |
| Product compatibility | GV3L, GV3P |
| Quantity per set | set of 1 |
| Pole contact composition | 1 NO + 1 NC |
| Mounting location | front side |
| Range | TeSys Deca, TeSys |
| Product or component type | auxiliary contact block |
| Range of product | TeSys Deca, TeSys GV3 |
| Complementary | |
| Rated operational power in W | 240 W at 48 V DC-13 - electrical durability: 100000 cycles, 180 W at 60 V DC-13 - electrical durability: 100000 cycles, 140 W at 24 V DC-13 - electrical durability: 100000 cycles, 140 W at 110 V DC-13 - electrical durability: 100000 cycles, 120 W at 240 V DC-13 - electrical durability: 100000 cycles |
| Depth | 29 mm |
| Width | 45 mm |
| Compatibility code | GVAED |
| Mechanical durability | 100000 cycles |
| Rated operational power in VA | 850 VA at 380-415 V AC-15 - electrical durability: 100000 cycles, 720 VA at 230-240 V AC-15 - electrical durability: 100000 cycles, 650 VA at 440-440 V AC-15 - electrical durability: 100000 cycles, 500 VA at 500-500 V AC-15 - electrical durability: 100000 cycles, 500 VA at 110-127 V AC-15 - electrical durability: 100000 cycles, 400 VA at 690-690 V AC-15 - electrical durability: 100000 cycles, 300 VA at 48-48 V AC-15 - electrical durability: 100000 cycles |
| Tightening torque | 1.4 N.m - on screw clamp terminals |
| Minimum switching voltage | 17 V |
| [Ui] rated insulation voltage | 600 V conforming to CSA C22.2 No 14, 690 V conforming to IEC 60947-1, 600 V conforming to UL 508 |
| Net weight | 0.05 kg |
| Protection type | gG fuse 10 A, GB2CB... circuit breaker |
| [Ue] rated operational voltage | 24...60 V DC, 24...240 V AC |
| [Ith] conventional free air thermal current | 2.5 A |
| Height | 11 mm |
| Minimum switching current | 5 mA |
| Environment | |
| Environmental characteristic | normal environment |
| Product certifications | UKCA |
