The 4 Position Clipsal Pro Series Rotary Switch has two "off" positions and two "on" positions. The 10A, 250V switch mechanism is ideal for fan control or other applications where you need two levels of speed or power.
Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Colour tint | white |
| Quantity per set | set of 20 |
| Range | Pro Series |
| Type of packing | polybag |
| Product or component type | selector switch |
| Complementary | |
| [Ue] rated operational voltage | 230/240 V |
| Depth | 32 mm |
| Width | 23 mm |
| Switch function | 4 positions |
| Device presentation | mechanism with central plate |
| Control type | rotary knob |
| Net weight | 0.016 kg |
| Material | ABS (acrylonitrile butadiene-styrene), PA66, PC (polycarbonate) |
| Clamping connection capacity | 1 x 4 mm² for stranded cable(s), 3 x 2.5 mm² for stranded cable(s), 1 x 1.5...4 x 1.5 mm² for rigid or stranded cable(s) |
| Marking | 0 - 1 - 0 - 2 |
| Surface treatment | untreated |
| Surface finish | glossy |
| Fixing mode | by clips |
| Rated current | 10 A |
| Height | 23 mm |
| Connections - terminals | screw terminal |
| Environment | |
| Relative humidity | 10-95 % |
| Ambient air temperature for operation | 0-45 °C |
| Product certifications | RCM |
