Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Control button type | 1 push-button |
| Device application | control |
| Plug, socket category | low voltage |
| Colour | grey (RAL 7035) |
| Device presentation | basic element with full cover plate |
| Range | Clipsal - 56 Series |
| Product or component type | time switch |
| Outlet standard deviation | Australian/New Zealand |
| Range of product | Series 56 |
| Product brand | Clipsal |
| Complementary | |
| Number of poles | 1 |
| Depth | 76.5 mm |
| Market segment | small commercial, industry, utility |
| Width | 101 mm |
| Protection type | without protection |
| Switch function | 1-pole |
| Poles description | 1P + N |
| Material | polycarbonate: cover |
| Local signalling | without |
| Tightening torque | 0.8 N.m |
| Control type | push-button |
| Colour code | GY |
| Connections - terminals | screw terminals 3 x 2.5-2.5 mm²rigid or stranded, screw terminals 4 x 1.5-1.5 mm²rigid or stranded |
| Net weight | 0.18 kg |
| Marking | without marking |
| Rated current | 10 AX, 15 A |
| Device mounting | surface |
| Height | 101 mm |
| [Ue] rated operational voltage | 250 V AC 50 Hz |
| Targeted country | Australia |
| Environment | |
| Outlet standard | industrial |
| IP degree of protection | IP66 conforming to AS 60529 |
| Standards | AS/NZS 3123, AS/NZS 3133 |
| Ambient air temperature for operation | 0-25 °C |
