Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Device application | power supply |
| Range | Clipsal - 56 Series |
| Product or component type | appliance inlet |
| Range of product | Series 56 |
| Product brand | Clipsal |
| Complementary | |
| Depth | 165 mm |
| Market segment | industry, utility, small commercial |
| Plug, socket category | low voltage |
| Width | 101 mm |
| Colour | grey (RAL 7035) |
| Outlet standard | industrial |
| [In] rated current | 32 A |
| Pin arrangement | I |
| Poles description | 1P + N + E |
| Material | polycarbonate: cover, plastic |
| Tightening torque | 0.8 N.m |
| Mounting mode | surface mounted |
| Voltage colour | blue |
| Colour code | GY |
| Net weight | 0.82 kg |
| Outlet standard deviation | Australian/New Zealand |
| Plug, socket, control station shape | straight |
| Contacts material | screws: brass |
| [Ue] rated operational voltage | 250 V 50/60 Hz conforming to EN 60309-2 |
| Duration | 6 h |
| Height | 204 mm |
| Targeted country | Australia |
| Connections - terminals | screw terminal 6-16 mm² rigid or stranded cable |
| Environment | |
| IP degree of protection | IP66 conforming to AS 60529 |
| Standards | AS/NZS 60320.1 |
| Ambient air temperature for operation | -25-75 °C |
