TeSys K control relay, 4 contacts (3NO + 1NC), 10A/690V, for control of electromagnetic loads AC-15/DC-13. It provides a 110V DC control circuit with no inrush consumption, connection by screw clamp terminals. For high operating rates until 180 cycles/min and ambient temperature -25/+50°C, it procures high reliability and durability. Compact (45mm width), for clipping on 35mm DIN rail or fixing by screw. Multi standards certified (IEC, UL, CSA, CCC, EAC).
Only registered users can write reviews
Related products
Auxiliary contact block, TeSys K, 1NO+3NC, front mounting, screw clamp terminals
LA1KN13
Auxiliary contact block, TeSys K, 1NO+3NC, front mounting, screw clamp terminals
$74.69 inc GST
$29.64 inc GST
Auxiliary contact block, TeSys K, 4NC, front mounting, screw clamp terminals
LA1KN04
Auxiliary contact block, TeSys K, 4NC, front mounting, screw clamp terminals
$71.28 inc GST
$28.29 inc GST
Auxiliary Contact Block, TeSys k, TeSys K, 2NO + 2NC, front mounting, screw clamp terminals
LA1KN22
Auxiliary Contact Block, TeSys k, TeSys K, 2NO + 2NC, front mounting, screw clamp terminals
$72.27 inc GST
$28.68 inc GST
Auxiliary Contact Block, TeSys k, TeSys K, 3NO + 1NC, front mounting, screw clamp terminals
LA1KN31
Auxiliary Contact Block, TeSys k, TeSys K, 3NO + 1NC, front mounting, screw clamp terminals
$71.39 inc GST
$28.33 inc GST
Auxiliary Contact Block, TeSys k, TeSys K, 4NO, front mounting, screw clamp terminals
LA1KN40
Auxiliary Contact Block, TeSys k, TeSys K, 4NO, front mounting, screw clamp terminals
$72.05 inc GST
$28.60 inc GST
clip-on marker holder, 8x17mm, for TeSys k contactor or reversing contactor
LA9D90
clip-on marker holder, 8x17mm, for TeSys k contactor or reversing contactor
$0.97 inc GST
$0.38 inc GST
