This MA100 is a 3 poles 3d magnetic trip unit used on ComPacT NSX 100/160/250 circuit breakers. This 100A rating magnetic trip unit is an optimum choice for motor protection applications. It embeds an adjustable instantaneous magnetic protection against short-circuits. This product is part of our EcoStruxure Power architecture if associated with PowerTag NSX and ComPacT NSX basic frame.
Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Device application | motor |
| Range compatibility | ComPacT new generation NSX250, ComPacT new generation NSX160, ComPacT new generation NSX100 |
| Mounting mode | fixed |
| Range | ComPacT new generation |
| Protection type | I : for short-circuit protection (magnetic) |
| Protected poles description | 3D |
| Range of product | ComPacT NSX100...250 new generation |
| Trip unit name | MA |
| Trip unit technology | magnetic |
| Poles description | 3P |
| Product or component type | trip unit |
| Network type | AC |
| Trip unit protection functions | I |
| [Ue] rated operational voltage | 690 V AC 50/60 Hz |
| [In] rated current | 100 A at 65 °C |
| Network frequency | 50/60 Hz |
| Complementary | |
| Instantaneous pick-up adjustment range | 6...14 x In |
| Earth-leakage protection | without |
| Instantaneous pick-up adjustment type Ii | adjustable 9 settings |
| Environment | |
| Ambient air temperature for storage | -50-85 °C |
| Pollution degree | 3 conforming to IEC 60947-1 |
| IP degree of protection | IP40 conforming to IEC 60529 |
| Ambient air temperature for operation | -25-70 °C |
| Electrical shock protection class | class II |
| Standards | EN/IEC 60947-2 |
