Products specifications
| Attribute name | Attribute value |
|---|---|
| Main | |
| Trip unit technology | thermal-magnetic |
| Device short name | C60H |
| Device application | distribution |
| Poles description | 4P |
| Breaking capacity | 30 kA Icu at 230...240 V AC 50/60 Hz conforming to EN/IEC 60947-2, 10000 A Icn at 230/400 V AC 50/60 Hz conforming to EN 60898 |
| Range | Multi9 |
| Product name | C60 |
| Product or component type | miniature circuit-breaker |
| Breaking capacity code | H |
| Network type | AC/DC |
| Number of protected poles | 4 |
| Curve code | B |
| Range of product | C60 |
| [In] rated current | 6 A |
| Complementary | |
| Depth | 73 mm |
| Width | 72 mm |
| Compatibility code | C60 |
| Limitation class | 3 |
| 9 mm pitches | 8 |
| Height | 81 mm |
| Environment | |
| Overvoltage category | IV |
| IP degree of protection | IP20 conforming to IEC 60529 |
